por
Clutch
12
10
11
9
7
8
6
5
4
3
2
1
1
Clutch housing, complete
880871
665,59€ Precio unitario con IVA
2
Washer
974320
8,35€ Precio unitario con IVA
3
Clutch hub
878845
No disponible
4
Clutch pressure plate
873719
220,87€ Precio unitario con IVA
5
Pressure plate spring
1A004625
13,97€ Precio unitario con IVA
6
Cup
879176
19,40€ Precio unitario con IVA
7
Hex socket screw M6
873718
5,87€ Precio unitario con IVA
8
Lathed driving clutch disc
875224
No disponible
9
Belleville spring
875223
46,46€ Precio unitario con IVA
10
Driving clutch disc
1A004602
62,34€ Precio unitario con IVA
11
Driven clutch disc
1A004603
62,34€ Precio unitario con IVA
12
belleville spring washer
875222
25,10€ Precio unitario con IVA
Los esquemas son meramente informativos. En caso de duda, nuestros especialistas están a su disposición para responder a sus preguntas. Al añadir una pieza al carrito, asegúrese de seleccionar la cantidad deseada. El precio unitario indicado corresponde a una unidad de cada referencia.
